| ATTRIBUTE | VALUE |
|---|---|
| Media: | Compressed air;Natural gas |
| Port size: | 1/2" NPT |
| Operation: | 3/2 |
| Actuation: | Sol/Spring |
| Function: | Normally closed |
| Voltage: | 24Vdc |
| Protection Class: | NEMA 4X;IP66 X8 |
| Seals: | Nitrile rubber |
| Body: | Stainless steel (316L) |
| Certification: | ATEX;IECEx;FM;T6 & T4 |
| Operating temperature: | -58 ... 194 °F |
| Flow coefficient: | 2.10 Cv |
| Operating pressure: | 0 ... 174 psi |
| Safety Integrity Level: | SIL 3 or SIL 4 (SIL 4 in Redundant configurations only) |
| Coil Encapsulation: | Class H |
| Solenoid Operation: | Automatic |
| Electrical connection: | M20 x 1.5mm ISO(F) |
