2866776
delivery time:8-10weeks
AC operation
Nominal input voltage range
100 V AC ... 240 V AC
Input voltage range
100 V AC ... 240 V AC -15 % ... +10 %
Derating
< 100 V AC (1 %/V)
Input voltage range AC
85 V AC ... 264 V AC
Input voltage range DC
90 V DC ... 350 V DC
Electric strength, max.
300 V AC
Typical national grid voltage
120 V AC
230 V AC
Voltage type of supply voltage
AC
Inrush current
< 20 A
Inrush current integral (I2t)
< 3.2 A2s
Inrush current limitation
20 A
AC frequency range
45 Hz ... 65 Hz
Frequency range DC
0 Hz
Mains buffering time
> 32 ms (120 V AC)
> 32 ms (230 V AC)
Current consumption
7 A (100 V AC)
5.8 A (120 V AC)
3 A (230 V AC)
3.1 A (240 V AC)
Nominal power consumption
569 VA
Protective circuit
Transient surge protection; Varistor
Power factor (cos phi)
0.89
Typical response time
< 0.6 s
Input fuse
12 A (slow-blow, internal)
Permissible backup fuse
B10 B16 AC:
Permissible DC backup fuse
DC: Connect a suitable fuse upstream
Recommended breaker for input protection
10 A ... 16 A (Characteristics B, C, D, K)
Discharge current to PE
< 3.5 mA
DC operation
Nominal input voltage range
110 V DC ... 250 V DC
Input voltage range
110 V DC ... 250 V DC -18 % ... +40 %
Derating
< 110 V DC (1 %/V)
Current consumption
6.3 A (110 V DC)
2.8 A (220 V DC)
